BLACKMAGIC DESIGN

Connections

• SDI Video Inputs    1 x 10-bit SD/HD/2K/4K. Supports 6 Gb/s 4:2:2 and 3 Gb/s 4:4:4
• SDI Video Outputs    1 x 10-bit SD/HD/2K/4K. Supports 6 Gb/s 4:2:2 and 3 Gb/s 4:4:4
• SDI Audio Inputs    16 Channels embedded in HD/2K/4K. 8 Channels embedded in SD
• SDI Audio Outputs    16 Channels embedded in HD/2K/4K. 8 Channels embedded in SD
• Sync Input    Tri-Sync or Black Burst
• Device Control    Sony™ compatible RS422 deck control ports. Serial ports TxRx direction reversible under software control
• Computer Interface    PCI Express 4 lane generation 2, compatible with 4, 8 and 16 lane PCI Express slots

Supported Codecs

• AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR & DNxHD, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes LT, Apple ProRes 422 Proxy, Uncompressed 8-bit 4:2:2, Uncompressed 10-bit 4:2:2, Uncompressed 10 bit 4:4:4

Software

• Included    Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility and Blackmagic driver on Mac OS and Windows. Media Express, Blackmagic Desktop Video Utility and Blackmagic driver on Linux
• Internal Software Upgrade    Firmware built into software driver. Loaded at system start or via updater software
• Physical Installation    PCI Express 4 lane generation 2, compatible with 4, 8, 16 lane PCI Express slots on Mac OS, Windows and Linux. Please check the Support pages to see the full system requirements

Software Applications

• DaVinci Resolve, Fusion, Final Cut Pro X, Adobe Premiere Pro CC, Avid Media Composer, Adobe After Effects CC, Avid Pro Tools, Steinberg Cubase, Autodesk Smoke, Adobe Photoshop CC, and more

Video Standards

• SD Video Standards    525i59.94 NTSC, 625i50 PAL
• HD Video Standards    720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080i50, 1080i59.94, 1080i60
• 2K Video Standards (SDI Only)    2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p
• Ultra HD Video Standards    2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30
• 4K Video Standards    4K DCI 23.98p, 4K DCI 24p, 4K DCI 25p
• SDI Compliance    SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 425M, SMPTE 2081, ITU-R BT.656 and ITU-R BT.601
• SDI Metadata Support    RP 188/SMPTE 12M-2 and closed captioning
• Audio Sampling    Television standard sample rate of 48 kHz at 24 bit
• Video Sampling    4:2:2 and 4:4:4 (*4K is 4:2:2)
• Color Precision    10-bit
• Color Space    REC 601, REC 709
• Multiple Rate Support    SDI video connections are switchable between SD/HD/2K and UHD

Processing

• HD Down Conversion    Built in, high quality hardware down converter outputs HD or SD on SDI output. Selectable between letterbox, anamorphic 16:9 and center cut 4:3 styles
• HD Up Conversion    Software based up conversion from SD to 720HD or 1080HD on capture. Selectable between 4:3 pillarbox, 14:9 pillarbox and 16:9 zoom
• Cross Conversion    Software based cross conversion from 720HD to 1080HD and 1080HD to 720HD on playback
• Real Time Effects    DaVinci Resolve, Final Cut Pro X internal effects. Premiere Pro CC Mercury Playback Engine effects. Avid Media Composer internal effects
• Colorspace Conversion    Hardware based real time
• Operating Systems    Mac 12.0 Monterey, Mac 13.0 Ventura or later; Windows 10, 64-bit; Windows 11; Linux

Power Requirements

• Power Consumption    11 W

Environmental Specifications

• Operating Temperature    5° to 40° C (32° to 104° F)
• Storage Temperature    -20° to 45° C (-4° to 113° F)
• Relative Humidity    0% to 90% non-condensing

What's Included

• DeckLink SDI 4K

Warranty

• 12 Months Limited Warranty
